Pulumi 를 사용하여 EKS Cluster 생성

aws console을 사용하다 보면 EC2 외에 보안그룹, EIP, 볼륨 등 다양한 리소스를 생성하게 된다. 이 때 리소스 삭제를 하는 경우 종속성 문제로 여러 메뉴들을 오가며 번거로운 작업을 할 때가 많다.



서비스가 많아지면 Infra를 관리를 위해 반복하는 작업이 많아지게 된다. 그래서 최근 Infrastructure as Code 와 관련된 기사를 많이 보게 된다. Public Cloud 관리를 위해 대표적으로 Terraform을 들수 있다.

Terraform은 쉽게 인프라를 구성할 수 있도록 해 주는 정말 좋은 도구이다. 하지만,  복잡한 구성 설정을 위해 필요한 HCL (HashiCorp Configuration Language) 를 배워야 하는 학습 곡선이 있다.



Pulumi는 개발자에게 익숙한 언어 ( Python, Go, Typescript, Javascript, .NET )을 사용하여 만들 수 있기 때문에 개발자라면 별도의 언어 학습 없이 Terraform에서 할 수 있었던 것을 할 수 있다는 장점이 있다.

설치

linux

# curl -fsSL https://get.pulumi.com | sh
=== Installing Pulumi v3.26.1 ===
+ Downloading https://get.pulumi.com/releases/sdk/pulumi-v3.26.1-linux-x64.tar.gz...
  % Total    % Received % Xferd  Average Speed   Time    Time     Time  Current
                                 Dload  Upload   Total   Spent    Left  Speed
100 63.4M  100 63.4M    0     0  8973k      0  0:00:07  0:00:07 --:--:-- 8925k
+ Extracting to /root/.pulumi/bin
+ Adding $HOME/.pulumi/bin to $PATH in /root/.bashrc

=== Pulumi is now installed! 🍹 ===
+ Please restart your shell or add /root/.pulumi/bin to your $PATH
+ Get started with Pulumi: https://www.pulumi.com/docs/quickstart

# source .bashrc

Windows

https://github.com/pulumi/pulumi/releases/ 사이트에서 압축파일을 다운로드 후 Path 에 지정한다.



샘플

pulumi는 처음 프로젝트를 생성할 때 pulumi cloud에 로그인하기를 요청한다. 하지만 오프라인에서도 아래와 같이 사용가능하다.

# pulumi login --local
Logged in to DESKTOP-xxx as DESKTOP-xxx\kmaster (file://~

login 후 프로젝트를 생성해 보자.

# pulumi new --help
Create a new Pulumi project and stack from a template.

To create a project from a specific template, pass the template name (such as `aws-typescript`
or `azure-python`).  If no template name is provided, a list of suggested templates will be presented
which can be selected interactively.

By default, a stack created using the pulumi.com backend will use the pulumi.com secrets
provider and a stack created using the local or cloud object storage backend will use the
`passphrase` secrets provider.  A different secrets provider can be selected by passing the
`--secrets-provider` flag.

To use the `passphrase` secrets provider with the pulumi.com backend, use:
* `pulumi new --secrets-provider=passphrase`

To use a cloud secrets provider with any backend, use one of the following:
* `pulumi new --secrets-provider="awskms://alias/ExampleAlias?region=us-east-1"`
* `pulumi new --secrets-provider="awskms://1234abcd-12ab-34cd-56ef-1234567890ab?region=us-east-1"`
* `pulumi new --secrets-provider="azurekeyvault://mykeyvaultname.vault.azure.net/keys/mykeyname"`
* `pulumi new --secrets-provider="gcpkms://projects/p/locations/l/keyRings/r/cryptoKeys/k"`
* `pulumi new --secrets-provider="hashivault://mykey"`

To create a project from a specific source control location, pass the url as follows e.g.
* `pulumi new https://gitlab.com/<user>/<repo>`
* `pulumi new https://bitbucket.org/<user>/<repo>`
* `pulumi new https://github.com/<user>/<repo>`

To create the project from a branch of a specific source control location, pass the url to the branch, e.g.
* `pulumi new https://gitlab.com/<user>/<repo>/tree/<branch>`
* `pulumi new https://bitbucket.org/<user>/<repo>/tree/<branch>`
* `pulumi new https://github.com/<user>/<repo>/tree/<branch>`

Usage:
  pulumi new [template|url] [flags]

Flags:
  -c, --config stringArray        Config to save
      --config-path               Config keys contain a path to a property in a map or list to set
  -d, --description string        The project description; if not specified, a prompt will request it
      --dir string                The location to place the generated project; if not specified, the current directory is used
  -f, --force                     Forces content to be generated even if it would change existing files
  -g, --generate-only             Generate the project only; do not create a stack, save config, or install dependencies
  -h, --help                      help for new
  -n, --name string               The project name; if not specified, a prompt will request it
  -o, --offline                   Use locally cached templates without making any network requests
      --secrets-provider string   The type of the provider that should be used to encrypt and decrypt secrets (possible choices: default,
passphrase, awskms, azurekeyvault, gcpkms, hashivault) (default "default")
  -s, --stack string              The stack name; either an existing stack or stack to create; if not specified, a prompt will request it
  -y, --yes                       Skip prompts and proceed with default values

Global Flags:
      --color string                 Colorize output. Choices are: always, never, raw, auto (default "auto")
  -C, --cwd string                   Run pulumi as if it had been started in another directory
      --disable-integrity-checking   Disable integrity checking of checkpoint files
  -e, --emoji                        Enable emojis in the output
      --logflow                      Flow log settings to child processes (like plugins)
      --logtostderr                  Log to stderr instead of to files
      --non-interactive              Disable interactive mode for all commands
      --profiling string             Emit CPU and memory profiles and an execution trace to '[filename].[pid].{cpu,mem,trace}', respectively
      --tracing file:                Emit tracing to the specified endpoint. Use the file: scheme to write tracing data to a local file
  -v, --verbose int                  Enable verbose logging (e.g., v=3); anything >3 is very verbose

Available Templates:
  aiven-go                     A minimal Aiven Go Pulumi program
  alicloud-csharp              A minimal AliCloud C# Pulumi program
  alicloud-fsharp              A minimal AliCloud F# Pulumi program
  alicloud-go                  A minimal AliCloud Go Pulumi program
  alicloud-javascript          A minimal AliCloud JavaScript Pulumi program
  alicloud-python              A minimal AliCloud Python Pulumi program
  alicloud-typescript          A minimal AliCloud TypeScript Pulumi program
  alicloud-visualbasic         A minimal AliCloud VB.NET Pulumi program
  auth0-csharp                 A minimal Auth0 C# Pulumi program
  auth0-go                     A minimal Auth0 Go Pulumi program
  auth0-javascript             A minimal Auth0 TypeScript Pulumi program
  auth0-python                 A minimal Auth0 Python Pulumi program
  auth0-typescript             A minimal Auth0 TypeScript Pulumi program
  aws-csharp                   A minimal AWS C# Pulumi program
  aws-fsharp                   A minimal AWS F# Pulumi program
  aws-go                       A minimal AWS Go Pulumi program
  aws-javascript               A minimal AWS JavaScript Pulumi program
  aws-native-csharp            A minimal AWS C# Pulumi program
  aws-native-fsharp            A minimal AWS F# Pulumi program
  aws-native-go                A minimal AWS Go Pulumi program
  aws-native-javascript        A minimal AWS JavaScript Pulumi program
  aws-native-python            A minimal AWS Python Pulumi program
  aws-native-typescript        A minimal AWS TypeScript Pulumi program
  aws-native-visualbasic       A minimal AWS VB.NET Pulumi program
  aws-python                   A minimal AWS Python Pulumi program
  aws-typescript               A minimal AWS TypeScript Pulumi program
  aws-visualbasic              A minimal AWS VB.NET Pulumi program
  azure-classic-csharp         A minimal C# Pulumi program with the classic Azure provider
  azure-classic-fsharp         A minimal F# Pulumi program with the classic Azure provider
  azure-classic-go             A minimal Go Pulumi program with the classic Azure provider
  azure-classic-javascript     A minimal JavaScript Pulumi program with the classic Azure provider
  azure-classic-python         A minimal Python Pulumi program with the classic Azure provider
  azure-classic-typescript     A minimal TypeScript Pulumi program with the classic Azure provider
  azure-classic-visualbasic    A minimal VB.NET Pulumi program with the classic Azure provider
  azure-csharp                 A minimal Azure Native C# Pulumi program
  azure-fsharp                 A minimal Azure Native F# Pulumi program
  azure-go                     A minimal Azure Native Go Pulumi program
  azure-javascript             A minimal JavaScript Pulumi program with the native Azure provider
  azure-python                 A minimal Azure Native Python Pulumi program
  azure-typescript             A minimal Azure Native TypeScript Pulumi program
  civo-go                      A minimal Civo Go Pulumi program
  civo-javascript              A minimal Civo TypeScript Pulumi program
  civo-python                  A minimal Civo Python Pulumi program
  civo-typescript              A minimal Civo TypeScript Pulumi program
  csharp                       A minimal C# Pulumi program
  digitalocean-go              A minimal DigitalOcean Go Pulumi program
  digitalocean-javascript      A minimal DigitalOcean JavaScript Pulumi program
  digitalocean-python          A minimal DigitalOcean Python Pulumi program
  digitalocean-typescript      A minimal DigitalOcean TypeScript Pulumi program
  equinix-metal-go             A minimal Equinix Metal Go Pulumi program
  equinix-metal-javascript     A minimal Equinix Metal JavaScript Pulumi program
  equinix-metal-python         A minimal Equinix Metal Python Pulumi program
  equinix-metal-typescript     A minimal Equinix Metal TypeScript Pulumi program
  fsharp                       A minimal F# Pulumi program
  gcp-csharp                   A minimal Google Cloud C# Pulumi program
  gcp-fsharp                   A minimal GCP F# Pulumi program
  gcp-go                       A minimal Google Cloud Go Pulumi program
  gcp-javascript               A minimal Google Cloud JavaScript Pulumi program
  gcp-python                   A minimal Google Cloud Python Pulumi program
  gcp-typescript               A minimal Google Cloud TypeScript Pulumi program
  gcp-visualbasic              A minimal GCP VB.NET Pulumi program
  github-csharp                A minimal GitHub C# Pulumi program
  github-go                    A minimal GitHub Go Pulumi program
  github-javascript            A minimal GitHub JavaScript Pulumi program.
  github-python                A minimal GitHub Python Pulumi program
  github-typescript            A minimal GitHub TypeScript Pulumi program.
  go                           A minimal Go Pulumi program
  google-native-csharp         A minimal Google Cloud C# Pulumi program
  google-native-go             A minimal Google Cloud Go Pulumi program
  google-native-python         A minimal Google Cloud Python Pulumi program
  google-native-typescript     A minimal Google Cloud TypeScript Pulumi program
  hello-aws-javascript         A simple AWS serverless JavaScript Pulumi program
  javascript                   A minimal JavaScript Pulumi program
  kubernetes-csharp            A minimal Kubernetes C# Pulumi program
  kubernetes-fsharp            A minimal Kubernetes F# Pulumi program
  kubernetes-go                A minimal Kubernetes Go Pulumi program
  kubernetes-javascript        A minimal Kubernetes JavaScript Pulumi program
  kubernetes-python            A minimal Kubernetes Python Pulumi program
  kubernetes-typescript        A minimal Kubernetes TypeScript Pulumi program
  linode-go                    A minimal Linode Go Pulumi program
  linode-javascript            A minimal Linode JavaScript Pulumi program
  linode-python                A minimal Linode Python Pulumi program
  linode-typescript            A minimal Linode TypeScript Pulumi program
  openstack-go                 A minimal OpenStack Go Pulumi program
  openstack-javascript         A minimal OpenStack JavaScript Pulumi program
  openstack-python             A minimal OpenStack Python Pulumi program
  openstack-typescript         A minimal OpenStack TypeScript Pulumi program
  python                       A minimal Python Pulumi program
  typescript                   A minimal TypeScript Pulumi program
  visualbasic                  A minimal VB.NET Pulumi program

위와 같이 github나 template에서 프로젝트를 생성할 수 있다. 이제 샘플로 eks를 생성해 보자.

$ pulumi new  https://github.com/pulumi/pulumi-eks/tree/master/examples/cluster-py
This command will walk you through creating a new Pulumi project.

Enter a value or leave blank to accept the (default), and press <ENTER>.
Press ^C at any time to quit.

project name: (example-cluster-py)
project description: (EKS cluster example)
Created project 'example-cluster-py'

stack name: (dev) test
Created stack 'test'
Enter your passphrase to protect config/secrets:
Re-enter your passphrase to confirm:

생성 후 폴더파일들을 보면 아래와 같다.

$ ls -al
total 20
drwxr-xr-x 1 net29 197609    0  4월  5 22:22 ./
drwxr-xr-x 1 net29 197609    0  4월  5 22:16 ../
-rw-r--r-- 1 net29 197609 1355  4월  5 22:21 __main__.py
-rw-r--r-- 1 net29 197609   85  4월  5 22:22 Pulumi.test.yaml
-rw-r--r-- 1 net29 197609  114  4월  5 22:23 Pulumi.yaml
-rw-r--r-- 1 net29 197609  189  4월  5 22:21 README.md
-rw-r--r-- 1 net29 197609   48  4월  5 22:21 requirements.txt
drwxr-xr-x 1 net29 197609    0  4월  5 22:22 venv/
-rw-r--r-- 1 net29 197609 1114  4월  5 22:21 vpc.py

__main__.py 와 vpc.py는 아래와 같다. ( 예제는 EKS Cluster를 2개 만들기 때문에 1개만 생성하도록 수정함 )

import pulumi
import pulumi_eks as eks

# Create an EKS cluster.
cluster = eks.Cluster(
    "test-cluster",
    instance_type="t2.medium",
    desired_capacity=2,
    min_size=1,
    max_size=2,
)

# Export the cluster's kubeconfig.
pulumi.export("kubeconfig", cluster.kubeconfig)

소스를 만들었으면,  eks 설치에 필요한 모듈을 설치하자.

# source venv/Scripts/activate
# (venv) pip install pulumi_eks

이제 실행 전 aws cli를 먼저 설치 후 환경설정을 한다. 설치는 아래 URL에서 확인한다. https://docs.aws.amazon.com/cli/latest/userguide/getting-started-install.html

Installing or updating the latest version of the AWS CLI - AWS Command Line Interface

설치가 완료되었으면 aws 환경설정을 진행한다.

# aws configure
AWS Access Key ID [None]:
AWS Secret Access Key [None]:
Default region name [None]:
Default output format [None]:

이제 pulumi를 실행해 보자.

$ pulumi up
Enter your passphrase to unlock config/secrets
    (set PULUMI_CONFIG_PASSPHRASE or PULUMI_CONFIG_PASSPHRASE_FILE to remember):
Previewing update (test):
     Type                                   Name                                            Plan
 +   pulumi:pulumi:Stack                    example-cluster-py-test                         create
 +   └─ eks:index:Cluster                   test-cluster                                    create
 +      ├─ eks:index:ServiceRole            test-cluster-eksRole                            create
 +      │  ├─ aws:iam:Role                  test-cluster-eksRole-role                       create
 +      │  ├─ aws:iam:RolePolicyAttachment  test-cluster-eksRole-4b490823                   create
 +      │  └─ aws:iam:RolePolicyAttachment  test-cluster-eksRole-90eb1c99                   create
 +      ├─ eks:index:ServiceRole            test-cluster-instanceRole                       create
 +      │  ├─ aws:iam:Role                  test-cluster-instanceRole-role                  create
 +      │  ├─ aws:iam:RolePolicyAttachment  test-cluster-instanceRole-e1b295bd              create
 +      │  ├─ aws:iam:RolePolicyAttachment  test-cluster-instanceRole-03516f97              create
 +      │  └─ aws:iam:RolePolicyAttachment  test-cluster-instanceRole-3eb088f2              create
 +      ├─ eks:index:RandomSuffix           test-cluster-cfnStackName                       create
 +      ├─ aws:ec2:SecurityGroup            test-cluster-eksClusterSecurityGroup            create
 +      ├─ aws:ec2:SecurityGroupRule        test-cluster-eksClusterInternetEgressRule       create
 +      ├─ aws:iam:InstanceProfile          test-cluster-instanceProfile                    create
 +      ├─ aws:eks:Cluster                  test-cluster-eksCluster                         create
 +      ├─ pulumi:providers:kubernetes      test-cluster-eks-k8s                            create
 +      ├─ eks:index:VpcCni                 test-cluster-vpc-cni                            create
 +      ├─ aws:ec2:SecurityGroup            test-cluster-nodeSecurityGroup                  create
 +      ├─ kubernetes:core/v1:ConfigMap     test-cluster-nodeAccess                         create
 +      ├─ aws:ec2:SecurityGroupRule        test-cluster-eksNodeClusterIngressRule          create
 +      ├─ aws:ec2:SecurityGroupRule        test-cluster-eksClusterIngressRule              create
 +      ├─ aws:ec2:SecurityGroupRule        test-cluster-eksNodeIngressRule                 create
 +      ├─ aws:ec2:SecurityGroupRule        test-cluster-eksNodeInternetEgressRule          create
 +      ├─ aws:ec2:SecurityGroupRule        test-cluster-eksExtApiServerClusterIngressRule  create
 +      ├─ aws:ec2:LaunchConfiguration      test-cluster-nodeLaunchConfiguration            create
 +      ├─ aws:cloudformation:Stack         test-cluster-nodes                              create
 +      └─ pulumi:providers:kubernetes      test-cluster-provider                           create

Resources:
    + 28 to create

Do you want to perform this update? no
confirmation declined, not proceeding with the update

위와 같이 28개의 resource가 생성되는 것을 확인할 수 있다.
